PVC Jacketed Stainless Steel TP304 Coil Tube 1/2'' OD x 0.049'' WT ASTM A269 Seamless/Welded with BA Finish for Instrumentation

PVC Jacketed Stainless Steel TP304 Coil Tube 1/2'' OD x 0.049'' WT ASTM A269 Seamless/Welded with BA Finish for Instrumentation


Features:

  • High-Quality Materials: 316 / 316L Stainless Steel and Copper Instrumentation Tubing
    Excellent corrosion resistance and mechanical strength, ideal for demanding industrial environments.

  • Wide Range of Sizes Available
    Tubing sizes from 1/4" to 1/2" (imperial) and 6 mm to 12 mm (metric) to accommodate various connection requirements.

  • Standard PVC Jacket – UV and Low-Temperature Resistant
    Durable PVC coating provides environmental protection, suitable for outdoor and low-temperature applications.

  • Optional TPU Jacket for High-Temperature Applications
    Thermoplastic Polyurethane (TPU) jacket available for environments requiring enhanced heat resistance and flexibility.

  • Custom Jacket Marking Available
    Jacket surface can be customized with media labels, specifications


  • Technical Parameters
  • Main feature
  • Operating range


Product Name
 PVC Coated Stainless Steel  Coil Tubing
Outside Diameter
3.2 mm – 25.4 mm
Wall Thickness
0.2 mm – 2.5 mm
Length
As per customer requirement; Available in coils or straight lengths
Standard
ASTM A269, etc.
Material Grade
TP304L, TP316, TP316L, TP321, etc.
Delivery Condition
Bright Annealed, PVC Coated
Manufacturing Process
Seamless / Welded
Application
Automotive, Aerospace, Instrumentation, Electrical, Chemical Industry, etc.
Marking
LOGO, Standard, Grade, Size, Heat Number
Packaging
Wooden Pallet, Wooden Case, or as per customer request
Quality Assurance
Mill Test Certificate (EN 10204/3.1); Factroy test report acceptable
