Stainless Steel Flange KF16/25/40/50 Blank Flange of Vacuum Fitting

Stainless Steel Flange KF16/25/40/50 Blank Flange of Vacuum Fitting

The KF ranges of flanges and fittings are manufactured from high quality stainless steel. KF flanges utilize an aluminium clamp with a single wing nut fastener allowing frequent disassembly without tools. The vacuum seal is affected by uniform application of pressure by the clamp on the 15 degree surface of the flange. The mating flange surfaces compress an 'O' ring held in place by a metal centering ring to produce a seal that can be used in high vacuum applications and baked to 200 degrees centigrade.

  • Material: 304 & 316 Stainless Steel; Flange Size: KF-16
  • 304 Stainless Steel fittings work in adverse temperatures and corrosive conditions.
  • The blank flange is commonly used for close unnecessary KF type connectors in the process system and also guarantee high vacuum performance of the whole system.
  • These Blank Flange fittings follow ISO-KF standards. They are often called quick flange fittings because they are quick to assemble.

  • Technical Parameters
  • Main feature
  • Operating range
 Product Name KF Stainless steel blank flange of vacuum fitting
 Size KF10,KF16,KF25,KF40,KF50
 Material Stainless Steel 304/316
TypeBlind Flange
 Connect Type Cap, Flange
 Surface Treatment Polishing
 Applictaiton Pharmacy,beer,food,dairy, beverage,cosmetic,chemical industry
